Customizable Heavy Duty Selective Pallet Racking Warehouse Rack System with 1000kg-3000kg Per Level Capacity Pallet Shelving

Product Description

Pallet Racking System
Pallet Racking System

The Industrial Pallet Racking System is composed of upright frames, beams, and accessories such as safety pins and foot plates. It is a versatile and widely used storage solution, suitable for storing palletized goods in warehouses, distribution centers, and manufacturing facilities.

Advantages and Features:
  • Robust Structure: Designed for heavy-duty applications with high load capacity and excellent stability.
  • Flexible Configuration: Adjustable beam levels to accommodate various pallet sizes and storage needs.
  • Efficient Space Utilization: Maximizes warehouse storage by optimizing vertical and horizontal space.
  • Compatibility: Suitable for storing different types of goods, including standard pallets, non-standard pallets, and bulk items.
  • Optional Accessories: Available with additional components like wire decking, safety bars, and back mesh for enhanced functionality and safety.
Specification
Specification Diagram
1. Frame 2. Beam
3. Safety locking mechanism 4. Frame union
5. Anchor bolts 6. Levelling shims
7. Upright protector 8. Lateral protection barrier
9. Cross bracing set 10. Top portal tie
11. Pallet cross tie 12. Container support
13. Chipboard shelving cross tie 14. Chipboard or melamine shelf
15. Galvanised picking shelf 16. Mesh shelf
17. Drum support 18. Pallet stop set
19. Anti-fall mesh 20. Raised cross tie
21. Aisle identification plate 22. Signalling plate
Pallet Racking Detail 1
Pallet Racking Detail 2
Product Description
Product Description 1
Product Description 2
Product Description 3
Product Description 4
Product Description 5
Product Description 6
Product Structure
Material Cold-Rolled Steel Q235B
Product Size Length: 2300 / 2500 / 2700 / 3000 / 3300 / 3600 / 3900mm
Width: 800 / 900 / 1000 / 1100 / 1200mm
Height: 2000 ~ 6500mm
(or Customizable)
Thickness column:1.5mm, 2.0mm
(or Customizable)
Load Capacity 1000KG~5000KG per layer
(or Customizable)
Layers 2-5 Adjustable Layers
(or Customizable)
Color Blue, Orange, Black, White, Grey
(or Customizable)
Surface Electrostatic Spray Surface
Feature Anti-rust, Corrosion-protection
Guarantee Period 5 Years Warranty
Remark OEM & ODM Accepted
Relevant Certificate CE, BV, ISO9001
Use Area Warehouse, Factory, Storage Place
Structure Knock Down Structure, Easy Assembling, Convenient For Delivery
Function storage goods, rack, storage
Product range warehouse, storage place
3D Drawing & Floor Plan Design
3D Design 1
3D Design 2
Layout Design 1
Layout Design 2
Technical Drawing 1
Technical Drawing 2
Successful Cooperation Cases
Project Case 1
Project Case 2
Project Case 3
Project Case 4
Project Case 5
Project Case 6
Our Factory
Factory Overview
About Our Company

Established in 2001, we are a trusted leader in the design, manufacturing, and installation of display stands, storage shelves, and supermarket equipment. With a factory spanning over 22,000 square meters and a skilled workforce of 120 employees, we deliver high-quality products at competitive prices to clients around the world.

Committed to excellence, we provide tailored warehouse storage solutions designed to optimize space and enhance efficiency for our customers. Guided by the principle of "Focused on Quality & Committed to Service," we aim to be your trusted global partner, delivering exceptional products and services to support your success.

Company Environment 1
Company Environment 2
Our Products

( All products can be customized )

  • Warehouse racking and warehouse equipment (warehouse pallet racking, light medium racking, heavy duty racking, mezzanine floor racking systems and storage pallet racking in warehouses/workplaces, including: cantilever racking systems, drive-in racking systems, wide span shelving, pallets flow rack, carton flow rack, etc.);
  • Supermarket shelves, store fixtures and equipment (supermarket gondola shelves, heavy duty gondola shelves, shopping carts, promotional carts, shopping baskets and cashier counters and other supermarket store equipment);
  • Hardware tool display stand, customized metal product display stand, etc. Our products are very popular in Southeast Asia, Japan, America, Canada, Australia and Europe. Over 40% of our annual orders come from repeat customers.
Product Collection

High Quality makes us own CE/ISO9001/BV Certification and have gained great credit from our foreign customers. We serve clients with the consistent principle of "Best Quality, Durable Structure, Perfect Design, Punctual delivery and Customer Satisfaction".

Our development relies on your active participation and we will make every effort for further development. With your support, we will move forward and further be the perfect shelving manufacturer and your best business partner!

Certification Display
Packing & Delivery
Packaging Process 1
Packaging Process 2
Loading 1
Loading 2
Frequently Asked Questions
Are you a manufacturing or trading company?
We are a manufacture. Our factory has been specializing in supermarket shelves, warehouse racks, and different kinds of display stands since 2001.
Can I visit your factory?
Yes, our factory is open for visits. You are warmly welcome to visit whenever you are available.
What is your delivery time?
In general, within 15 days. It also depends on the order quantity and shelving design.
What is the term of payment?
Payment terms: 30% of deposit upon signing the PI, and the balance will be cleared by T/T before delivery.
Could you produce according to customers' designs?
Sure, we have very rich experience in customizing shelves.
What are the main rack and add-on rack?
The difference between these two kinds of racks is the uprights. The main rack is the start rack with 2 uprights, and the add-on rack is the continuation rack with only 1 upright. For example, if there are 15 wall racks against a wall, the structure will consist of 1 main rack and 14 add-on racks.
